The buildout:
Ladder for access to rooftop
Handcrafted interior in finish option: White
Swivel Seat on passenger side
Four windows
Maxxair fan – Dual Direction
3M Insulation
Sliding Door Seat Lagun Table

CABINETS:
Galley cabinet -5 feet long
Bamboo countertops
Two burner cooktop
110L integrated stainless steel fridge
Door latches
Overhead cabinets from front to back
10.25 feet long
Under cabinet led lights
Door latches

REMOVABLE BED PLATFORM:
35 inch clearance – Fits most bikes
Open concept for storage and accessibility
Bed dimensions: 72″ in length, 68″ width (wall to wall), 77” in to window
6-inch Queen Size Memory Foam Mattress

ELECTRICAL SYSTEM:
(1) EcoFlow DELTA Pro 3600wh
(1) EcoFlow DELTA Pro Expansion Battery
DC-DC Charging while driving
(1) 450w Renogy solar panel
(1) 3600w Inverter – 7200w surge with 4 outlets
(1) Fuse Block
(1) 600w inverter for charging the Ecoflow while driving
(2) 12v plug inserts
(8) USB plug inserts
(2) Dimmable reading lights
(1) Power system control with Ecoflow App
(1) 30 amp output socket

WATER SYSTEM
(1) 25- gallon water tanks
No grey water tank – plumbed straight to the ground
12V water pump 3 gallons/minute
Braided nylon hose plumbing
Gooseneck Faucet (for outdoor shower use)
Large sink – 16″ x 14″
Drinking Water Filter

ADDITIONAL FEATURES:
Fuel-Activated Heater
Dometic Cassette Toilet
Bug Screen on Rear and Slider Doors
Gas, smoke, and Carbon monoxide detectors
Fire extinguisher
Power system control with Ecoflow App
